073/23

41.

42.

43.

44.

45.

46.

Method of terminating a wall with alternate courses projecting is known as
A) Brick nogging B) Brick laying C) Racking D) Toothing

Piece of timber in door or window fixed in an inclined position within a frame is
known as

A) Jamp B) Louvre C) Mullion D) Transom

The end bearing for lintels should be greater than
i. 100 mm

ii. Depth of lintel

ii. Breadth of brick wall

iv. 1/12" of span

Out of the above, which option is correct ?

A) All the above B) Only i, ii and iii
C) Only i, ii and iv D) Only iii and iv
Match List — | with List — Il. Match the terms with its correct explanation.
List -1 List - ॥
1. Battens i. Rafters, which run diagonally from ridge to
the eaves
Il. Purlins ர்‌. Rafters, which run diagonally from ridge to
the corners of the wall
lll. Hip rafters ர்‌. Rafters, which run from hip to the valley
IV. Valley rafters iv. Members nailed to the rafters to give supports
for the roof covering material
V. Jack rafters v. Members supported by truss or wall and are

used to support the common rafters
١١١ ४ ४

^) ४ ५४ ‏لا‎ ii i
ठ) ४५ ۷ ii i iii
Cc) v ‏۷ا‎ i iii ர்‌
0) ५ ४५ ‏لا‎ ii i

As per IS 456 : 2000, the minimum period before striking formwork for soffit formwork
to beams is

A) 3 days 8) 5 days C) 7 days D) 10 days

List the methods of post-tensioning in prestressed concrete.
|. Freyssinet system
Il. Magnel-Blaton system
Ill. Baur-Leonhardt system
IV. Lee-McCall system
A) I, ll, Ill and IV 8) Only | and II
C) Only | and IV D) Only I, Il and IV
