098/23
10. State the graph shown here correspond to which category
A) Variation on impedance and current in a resistive circuit
B
௦
)
) Variation on impedance and current in a parallel resonant circuit
) Variation on impedance and current in a series resonant circuit
D) Variation on impedance and current in a capacitive circuit
11. As the temperature increases beyond the curie temperature, the relative susceptibility
of ferromagnetic materials
A) Increase B) Remains constant
C) Becomes zero D) Decrease
12. If the area of hysteresis loop of a material is large, the hysteresis losses in the material
will be
A) Zero B) Large
C) Small D) Unchanged
13. The total inductance of 2 coils connected in series cumulatively is 1.6 H and connected
in differentially is 0.4 H. If the self inductance of one coil is 0.6 H then coupling
coefficient will be
A) 0.612 B) 1.2
C) 3 D) 2.5
14. The induced emf in a magnetically linked coil when its flux is changed from 1 Wb to
0.1 Wb in 0.1 second is
B) 0.09 V 0) 0.9% 0) 9% ۷ھ
